ProOes-6621-R – Reversing aid with LED display (four rear reversing sensors)

Our ProOes-6621-R reversing aid with LED display – unique on the market because it is individually programmable. One of the most advanced reversing aids on the market with high-precision distance measurement and map programming. Features 4 digital reversing sensors at the rear with sensors suitable for any design and scenario. The system comes with normal default settings and can be installed like any other simple reversing system without additional programming. However, this reversing aid offers the option of adjusting the sensor very precisely to the vehicle, especially in cases where there are deviations from the norm, and programming it very accurately. This allows different sensor heights and different depths to the vehicle edge to be programmed to suit the vehicle geometry, which significantly increases the accuracy of distance warnings compared to standard systems without adjustment.

Product features:

• Minimal blind spot thanks to 4 digital ProOes XXL rear parking sensors
• Can be installed in virtually any vehicle thanks to various mounting options and included angle adapters.
• Can be mounted inside the bumper or with an angle adapter from the outside of the bumper
• The sensor system works very accurately and, depending on the installation, can indicate a distance of up to 15 cm before a continuous warning tone sounds.
• Docking distance / continuous tone adjustable to a distance of 15 cm from the obstacle (standard on the market is 30 cm)
• Highly reliable detection even with difficult obstacles or poor weather conditions
• Obstacles are detected from a distance of 2.5 meters
• Waterproof sound sensors and waterproof cabling to the alarm box.
• The system operates at temperatures ranging from -35 to +80°C and is therefore highly reliable.
• Self-test function; indicates a defective sensor with a warning tone, and the other sensors continue to operate by deleting the faulty sensor.
• Sensors can be programmed for any vehicle shape during installation.
• Environment analysis: Fixed obstacles such as trailer hitches or attachments can be recognized by the system as “fixed obstacles” through an environment analysis and excluded from the calculation.
• If the sensors cannot be mounted according to standard (different heights and depths), the system can be programmed very precisely. This allows the system to display accurate readings down to 10 cm, even with difficult vehicle shapes.
• 10.5 ~ 28V DC (operating voltage)

Programming the sensors:

The system comes with default settings and can therefore be installed as standard. This means that programming is not absolutely necessary. However, our system offers the unique option of precisely adjusting the sensors to specific problems in cases of difficult vehicle geometries or special circumstances. This requires a separate programming box and a special application, which can be purchased from us or provided for a fee.

Scope of delivery:

• New goods in original packaging as described above
• 1 Reversing aid ProOes-6621-R
